Dual Bend

3D Dual Bend Tape provides unmatched flexibility, capable of bending seamlessly in any direction—both vertically and horizontally—making it ideal for complex Urban extrusion designs. Its 3D bendability is paired with a CRI of 97+ for accurate color rendering, low bin tolerance under the 1.5 Step McAdam Ellipse standard, and high efficacy. With a wide range of Kelvin temperatures and factory-soldered lead wires, 3D Tape is a dependable choice for versatile and precise lighting applications.
Dual Bend

Features

  • 3D Dual bendable on both horizontal and vertical planes
  • Perfect for all bendable Urban extrusion
  • Low bin tolerance with a 1.5 Step McAdam Elipse standard
  • High efficacy value
  • High CRI 97+
  • Factory soldered lead wire
  • Large range of available Kelvin temperatures
  • Low lead times
  • 5 Year warranty



Specs

  • Voltage = 24V DC
  • Lumen Output (lm/ft) = 200-300, 300-400, 400-500
  • Power Consumption (W/ft) = 4.4W
  • Max Run (ft) = 20'
  • Dimming = MLV, ELV, 0-10V, DMX
  • Environment = Dry Location
  • IP Rating = IP20
  • LED Color ( Kelvin Temp ) = 1800K, 2200K, 2400K, 2700K, 3000K, 3500K, 4000K, 5000K
  • CRI = 94+
  • Efficacy (lm/W) = Up to 94
  • Lumen Maintenance (L70) Hours = 60,000
  • Certifications = cULus
  • Warranty = 5 Years
